Deye GB-L-PACK4.0 HV LITHIUM BATTERY STACKABLE 102.4V, 40AH, 4.09KWH, IP65 Поставщики, Компания

Model	GB-L
Main Parameter
Cell Chemistry	LiFePO₄
Module Energy(kWh)	4.09
Module NominalVoltage(V)	102.4
Module Capacity(Ah)	40
Battery system model	GB-L8	GB-L12	GB-L16	GB-L20	GB-L24
Battery Module Qty InSeries(Optional)	2	3	4	5	6
System Nominal Voltage(V)	204.8	307.2	409.6	512	614.4
SystemOperating Voltage(V)	166.4~700
SystemEnergy(kWh)	8.18	12.27	16.36	20.45	24.56
System Usable Energy (kWh) 1	7.36	11.04	14.72	18.4	22.08
Charge/Discharge Current (A)	Recommend 20
	Nominal 40
	PeakDischarge(2 mins,25°C) 50
Working Temperature(°C)	Charge: 0~55/Discharge: -20~60
LCD Display	SOC%,Power,Total Voltage
Communication Port	CAN2.0,RS485
Humidity	5%~90%
Altitude	≤2000m
IP Rating of Enclosure	IP65
Storage Temperature(°C)	0~35
Dimension (W/D/H,mm)	540385650	540385870	5403851090	5403851310	5403851530
Weight(kg)	97	136	175	214	253
Installation Location	Floor Mount
Recommend Depth of Discharge	90%
CycleLife	25±2°C,0.5C/0.5C,EOL70%≥6000
Warranty 3	10years
Certification	CE/IEC62619 /VDE2510-50/ UL1973/UL9540A/UN38.3

1 DC Usable Energy, test conditions: 90% DOD, 0.2C charge & discharge at 25°C. System usable energy may vary due to system configuration parameters.
2 The current is affected by temperature and SOC.
3 The warranty is due whichever reached the first of the warranty period or life cycle power.

System Components

Model	GB-LBS
Description	High voltage battery cluster control box
Operating Voltage	120～750Vdc
Nominal Charge/Discharge Current	40A
Max Charge/Discharge Current	50A
Operating Temperature Range	-20~65°C
Ingress Protection	IP65
Dimension (W/D/H)	540385110mm
Weight Approximate	12kg

Model	GB-LM4.0
Description	4.09kWh battery module
Battery Type	LiFePO4(LFP)
Nominal Voltage	102.4Vdc
Rated Capacity	40Ah
Rated Energy	4.09kWh
Nominal Charge/Discharge Current	40A
Peak Discharge Current	50A
Charge Temperature	0~55°C
Discharge Temperature	-20℃～60℃
Storage Temperature	0℃～35℃
Ingress Protection	IP65
Dimension (W/D/H)	540385220mm
Weight Approximate	39kg

Model	GB-LBase
Description	Battery module base
Dimension (W/D/H)	540385100mm
Weight Approximate	7kg

Model	ECOM Cable2.0
Description	Standard 2-meter communication cable connected to the external device

Model	EPCable2.0
Description	Standard 2-meter power cable connected to the positive pole of the external PCS
1000V/6AWG Cable

Model	ENCable2.0
Description	Standard 2-meter power cable connected to the negative pole of the external PCS
1000V/6AWG Cable
